- Size: 5200x1650x2720mm
- Place of Origin: Qingzhou
- Brand Name: SWGM/HERACLES
- Model Number: HR910F
- Weight: 3300.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
- :
Product Description
1.Using direct injection diesel engine as power, with easy startup and low oil consumption
2.Using special drive axle, with strong ability to overcome obstacle
3.Chassis uses hinged structure, with small turning radius and flexible turning, which applies to the operation in narrow space
4.This machine uses hydraulic operation, with simple structure, convenient operation, good performance and reliable quality
5.Widely applying to the construction of agricultural engineering and small and medium building such as road, coal mine, 6.brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc.
Model | HR910F | |
A | Overall length with standard bucket | 4860 |
B | Overall length excl. bucket | 4150 |
C | Axle center up to bucket hinge pin | 946 |
D | Wheelbase | 2150 |
E | Rear overhang | 925 |
F | Height to top of cabin | 2570 |
G | Seat height | 1470 |
H | Total working height | 3868 |
I | Max.height of bucket pivot | 3130 |
J | Overhead loading height | 3010 |
K | Max.dumping height | 2650 |
L | Operating di s tance for K | 942 |
M | Track width | 1330 |
N | Ground clearance | 270 |
P | Wheel outside width | 1550 |
R | Inside turning radius | 2546 |
S | Radius at the outer edge | 4272 |
T | Max.turning radius | 4652 |
U | Turning angle | 35° |
V | Rollback angle at max.lifting height | 50° |
W | Dumping angle | 40° |
X | Backroll angle on the ground | 45° |
THE TECHNICAL PARAMETERS OF HR910F CE CERTIFICATE MINI WHEEL LOADER | ||
Bucket Capacity(m³) | 0.5 | |
Operating Weight(kg) | 3300 | |
Bucket Width(mm) | 1650 | |
Rated Load(kg) | 1000 | |
Brake Mode | Four-wheel hydraulic spead-shoed brake | |
Driving Mode | Four-wheel drive | |
Overall Dimensions (mm)(L*W*H) | 5200x1650x2720 | |
Max. Breakout Force(KN) | 32 | |
Forward Speed 1st(km/h) | 0-12 | |
Forward Speed 2nd(km/h) | 0-25 | |
Reverse Speed (km/h) | 0-25 | |
Max. Dumping Height(mm) | 2650 | |
Max. Dumping Reach (mm) | 850 | |
Min. Turning Radius(mm) | 3890 | |
Full Bucket Lifting Time (s) | 4.5 | |
Total Hydraulic Cycle Time (s) | 9 | |
Tread Width (mm) | 220 | |
Wheel Base (mm) | 1580 | |
Min. Clearance Over Ground (mm) | 230 | |
MAX. Tilt Angel(°) | 30 | |
Diesel Engine | Brand | Yunnei Engine |
Optional brand | Euro3 and EPA Xinchai Engine Imported Yanmar/Perkins/Kubota/Cummins Engine | |
Type | In-line arrangement,Four-stroke,Water cooled, 4-cylinder diesel engine | |
Rated Output(KW) | 37KW | |
Rated Speed (rpm) | 2300 | |
Engine starting mode | Electric | |
Transmission | Type | Hydraulic converter |
Drive axle | Type | Isuzu drive axle |
Rear Axle Oscillation | Center oscillation | |
Oscillating Angle Of Rear Axle | 13° | |
Tire | Model | 12.00-16 |
Optional model | 12-16.5 or 14-17.5 Wider Tyre 31*15.5-15 Agriculture Tyre | |
Steering System | Working Pressure (MPa) | 10 |
Steering System | Articulated Frame with hydraulic power steering | |
Max. Steering Angle (°) | 35 | |
Working Hydraulic System | Pressure Of Tire (MPa) | 2.5-3.5 |
Working Pump Type | Gear pump | |
Working Pressure (MPa) | 16 | |
Brake System | Service Brake | Four Wheel Hydraulic spread-shoed brake |
Parking Brake | Hand operated | |
Package | 1 unit in 20GP,3 units in 40HQ. | |
Delivery time | 25 days after 30% down payment. | |
Warranty | 12 months after delivery. | |
