HR912M small cheap side loader forklift for sale

HR912M small cheap side loader forklift for sale

  • Min.Order Quantity: 1 Set
  • Supply Ability: 500 Sets per Month
  • Port: Qingdao port
  • Payment Terms: L/C,T/T,Western Union
Get Latest Price:
  • *Quantity: Set/Sets
| Factory
Experience:2013-11-01
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Size:  4800*1700*2700mm
  • Place of Origin:  Qingzhou
  • Brand Name:  SWGM/HERACLES
  • Model Number:  HR912M
  • Weight: 2880.000 kg

Specifications Of HR912M mini wheel loader with price:



1.0 Engine Details

    (1) Model :                                            YN25GB

    (2) Engine type:   In-line arrangement, water cooled, four-cycle diesel Engine

    (3) Rated Power :                                        37KW

    (4) Rated Speed :                                   2400 r/min(rpm)

    (5) Fuel Consumption ratio in standard working condition :    269g/kw.h

2.0 Steering System

    (1) Cycloid full hydraulic steering system :                    BZZ-125

    (2) System Pressure                  :                       10MPa

    (3) Steering Cylinder                 :                Φ76x Φ63x180

    (4) Speed



3.0 BUCKET

    (1) Bucket Capacity     :                                    0.6m³

    (2) Bucket width       :                                    1685mm

    (3) Bucket type        :                        Heavy duty bolt on teeth

    (4) Max. Breakout Force :                                       32KN

    (5) Rated Load        :                                      1200kg

    (6) Operating Weight   :                                      2880kg

4.0 OVERALL DIMENSION

    (1) Overall Length ( Bucket on ground position )  :                4900mm

    (2) Overall Height

            (a) Ground to Cab Top :                              2580mm

            (b) Ground to exhaust pipe :        It is below from the top of cabin

            (c) Dumping Height  :                               2650mm

    (3) Overall Width            :                               1685mm

5.0 OPERATING SPECIFICATIONS

    (1) Drive Means             :                        Four-wheel drive

    (2) Min Turning Radius       :                               4200mm

(3) Driving System           :                             Mechanical

(4) Dumping Height          :                               2545mm

(5) Min Base to the ground     :                               240mm

(6) Time of raise             :                               3.05sec.

(7) Hydraulic cycle time       :                                  9sec.

6.0 Brake System

    (1) Service Brake :                Four Wheel Hydraulic spread-shoed brake

    (2) Parking Brake :                                      Hand operated

7.0 Wheelbase :                                               2040mm

8.0 Track :                                                   1320mm

9.0 Machine speed

(1)Low speed  (km/h)    4             2High speed (km/h)    25

10.0 Tire:                                                     14/90-16

Equipment:



Standard bucket with general-purpose teeth



Bucket’s teeth with quick mounting screws



Bucket capacity 0.6m³



Optional pallet forks, log gripper, snow plough, sweeper, concrete mixer, gripper,

quick hitch

David Li   Mobile: 86 13258070039

                E-mail: heracles@swgm.cc

                Skype: cnheracles


  • Size:  4800*1700*2700mm
  • Place of Origin:  Qingzhou
  • Brand Name:  SWGM/HERACLES
  • Model Number:  HR912M
  • Weight: 2880.000 kg

1.0 Engine Details

    (1) Model :                                            YN25GB

    (2) Engine type:   In-line arrangement, water cooled, four-cycle diesel Engine

    (3) Rated Power :                                        37KW

    (4) Rated Speed :                                   2400 r/min(rpm)

    (5) Fuel Consumption ratio in standard working condition :    269g/kw.h

2.0 Steering System

    (1) Cycloid full hydraulic steering system :                    BZZ-125

    (2) System Pressure                  :                       10MPa

    (3) Steering Cylinder                 :                Φ76x Φ63x180

    (4) Speed



3.0 BUCKET

    (1) Bucket Capacity     :                                    0.6m³

    (2) Bucket width       :                                    1685mm

    (3) Bucket type        :                        Heavy duty bolt on teeth

    (4) Max. Breakout Force :                                       32KN

    (5) Rated Load        :                                      1200kg

    (6) Operating Weight   :                                      2880kg

4.0 OVERALL DIMENSION

    (1) Overall Length ( Bucket on ground position )  :                4900mm

    (2) Overall Height

            (a) Ground to Cab Top :                              2580mm

            (b) Ground to exhaust pipe :        It is below from the top of cabin

            (c) Dumping Height  :                               2650mm

    (3) Overall Width            :                               1685mm

5.0 OPERATING SPECIFICATIONS

    (1) Drive Means             :                        Four-wheel drive

    (2) Min Turning Radius       :                               4200mm

(3) Driving System           :                             Mechanical

(4) Dumping Height          :                               2545mm

(5) Min Base to the ground     :                               240mm

(6) Time of raise             :                               3.05sec.

(7) Hydraulic cycle time       :                                  9sec.

6.0 Brake System

    (1) Service Brake :                Four Wheel Hydraulic spread-shoed brake

    (2) Parking Brake :                                      Hand operated

7.0 Wheelbase :                                               2040mm

8.0 Track :                                                   1320mm

9.0 Machine speed

(1)Low speed  (km/h)    4             2High speed (km/h)    25

10.0 Tire:                                                     14/90-16
