Performance

1

Rated loading

2200kg

2

Overall weight

5000kg

3

Rated bucket capacity

1.2m³

4

Maximum tractive force

≥54KN

5

Maximum breakout force

≥45.4KN

6

Maximum grade ability

30°

7

Maximum dump height

2900/3100/3300mm

8

Maximum dump reach

752mm

9

Overall dimension (L×W×H)

5890×2120×2850mm

10

Minimum turning radius

5251mm

Engine

11

Model

Yunnei turbocharged engine

12

Optional model

Weichai/Cummins engine

13

Type

Vertical, in-line, water cooled, 4-stroke diesel engine

14

Rated power

65KW

15

Rated speed

2200rpm-2400rpm

16

Engine starting mode

Electric

Transmission system

17

Gearbox mode

Counter shaft power-shift

18

Gear shift

2 forward shift 2 reverse shift

19

Maximum speed

25km/h

Drive axles

20

Main reducing spiral

Circular Arc Bevel gear, single stage

21

Decelerating mode

Single stage planetary type

22

Wheel base (mm)

2400mm

23

Wheel tread

1640mm

24

Ground clearance

310mm

25

Driving mode

Four-wheel full hydraulic drive

Tire

26

Tire type

16/70-20

27

Optional tire

16/70-24

Brake

27

Brake mode

Air assist disc brake on 4 wheels

Packaging

28

Packaging details

Nude package,1 unit in 20GP,2 units in 40HQ.

29

Port

Qingdao

Delivery time

30

15-25 days after 30% down payment.

Warranty

31

15 months after delivery.
