Cab Roof Height: 2,900MM

Wheel Base: 2,250MM

Track: 1,640MM

Min. Ground Clearance: 300MM

Total Weight: 7,600KG

Maximum Speed: 22Km/h

Maximum Grade ability Capacity: 30°

Loading Bucket Capacity: 1.6CBM

Loading Capacity: 2,800KG

Maximum Articulated Height Of Bucket: 3,400MM

Bucket Discharge Height: 2,795MM

Bucket Discharge Distance: 1,048MM

Backhoe Bucket Capacity: 0.32CBM

Backhoe Discharge Height: 3,878MM

Maximum Digging Depth: 4,300MM

Minimum Turning Radius: 5,688MM

Bucket Slewing Angle: 190°

Bucket Stick Revolving Radian: 180°

Diesel Engine

Model: Yuchai  turbocharged engine

Engine Power:85KW

Type: Inline, direct injection, four-stroke, liquid cooled

Optional engine:  Weichai turbocharged engine(83KW)

                Cummins engine 4BTA3.9-100(75KW)

Rated Speed: 2,400RPM

Transmission System

Type of Hydraulic Pump: Fixed shaft power shift transmission

Gear Shift: 2 forward shift 2 reverse shift

Torque: YJ-280

Drive Pump: CDXaf3016-IL

Flow: 16ML/R

Work Pump: CBGj2063

Flow: 63ML/R

Steering System

Type: Articulated hydraulic steering

Steering Control Valve: BZZ5-250

Turning Control Valve: YSF25S-00

Steering Angle: 36°

Minimum Turning Radius: 5,018MM

Axles

Main Transmission Type: Single Reduction

Wheel Reduction Type: Wheel Reduction

Tyre

Tyre Size: 16/17-24

Front Wheel Pressure: 0.22MPa

Rear Wheel Pressure: 0.20MPa

Brake System

Service Braking: Air over hydraulic disc on 4 wheels

Parking Brake: Manual parking brake

Hydraulic System

System Flow: 140L/Min

Bucket Digging Capacity: 46KN

Bucket Stick Digging Capacity: 31KN

Bucket Hydraulic Translation Function: Yes

Bucket Lift Time: 6.8S

Bucket Lower Time: 2.5S

Bucket Dump Time: 1.2S
