- Size: 6600x1800x2680mm
- Place of Origin: Qingzhou
- Brand Name: SWGM/HERACLES
- Model Number: TL1500
- Weight: 1500.000 kg
1.The telescopic boom which can reach 4.5m greatly increase it’s working scope.
2.The articulated structure and axle transmission design makes it powerful and has better pass through ability.
3.The seals, valve & joystick handle are famous oversea products which guarantee that it’s a reliable long lasting machine.
4.Adjustable spring seat and optional air conditioner makes the operating more comfortable.
5.Wide view cabin and two entrance makes the operating convenient and safe.
6.Quick coupling system, mechanic joystick and buttons makes the operating easy and convenient.
7.The rear cover can be opened as a whole part just by your hands, which makes the maintenance much more simple.
- Size: 6600x1800x2680mm
- Place of Origin: Qingzhou
- Brand Name: SWGM/HERACLES
- Model Number: TL1500
- Weight: 1500.000 kg
TL1500 Specification | ||
TL1500 | Overall Dimension: | 6600x1860x2680mm |
Rated load: | 1500kg | |
Bucket width: | 1600mm | |
Bucket capacity: | 0.65m³ | |
Bucket type | Heavy-duty bolt on teeth | |
Engine | Model: | Yunnei engine |
Rated Speed | 2400 r/p.min (rpm) | |
Type | In-line arrangement, water-cooled, four-cycle diesel Engine | |
Transmission System | Hub reduction axle | |
drive shaft | ||
Hydraulic converter | ||
Steering System | Min. Turning Radius: | 4950mm |
Service brake | Safer air assist disc brake braking system | |
Parking brake: | Hand operated（Disc brakes） | |
Tyre | Model | 20.5-16 |
Width: | 300mm | |
Diameter | 900mm | |
Wheelbase
| 2400mm | |
Track | 1345mm | |
Package: | one set fill in 20 foot container,2sets fill in 40 high foot container
| |
Delivery time | Shipped in 20 days after payment | |
